Technical File of SRSTS-WL-UX Wire rope tension test system
1
User’s Guide
SRSTS-WL-UX
(V1.0)
Xi'an Excellent Electromechanical Co., Ltd.
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
2
页
Table of Contents
一、
Product Overview
……………
Page 3
……………
Page 4
Page 5
二、
Sensor
……………
Page 6-7
三、Method and description of wire rope tension tester
Page 7-12
四、
Application scope Working
principle and main features
……………
Page 13
……………
Page 13
五、五、Technical Specifications
Specifications
Page 14
promise
……………
Page 15
Other
……………
Page 15
Notice: In any case, we are only responsible for the quality of the products during the warranty period.
Disclaimer: Due to technological progress, the company reserves the right to change the product; For technical
specifications, please refer to the manual delivered with the product.
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
3
页
一.Product Overview
1.Product appearance and function introduction
2.
Wire rope tension tester SRSTS-WL-UX sensor interface description
Tablet computer: Connect the
tester through Bluetooth, display
the tester to measure the force
change of the wire rope.
Tester: Connect wire rope
sensor, connect tablet
computer via Bluetooth to
transmit data.
Wire rope tension sensor:
Detect the tension change of
wire rope due to the change
of car load.
Tester charger: 220V
power supply.
Tablet charger: 220V
power supply.
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
4
页
Wire rope tension tester SRSTS-WL-UX sensor interface description
Added custom port
option
Bit number and
identification
Function and definition
Remark
Input port
IN1
Wire rope tension sensor input port 1
IN2
Wire rope tension sensor input port 2
IN3
Wire rope tension sensor input port 3
IN4
Wire rope tension sensor input port 4
IN5
Wire rope tension sensor input port 5
IN6
Wire rope tension sensor input port 6
IN7
Wire rope tension sensor input port 7
IN8
Wire rope tension sensor input port 8
Charger
interface
DCIN
Charger interface, input AC 220V,
output DC8.4V
power switch
ON/OFF
power switch
Bluetooth antenna
ANT
Bluetooth antenna interface
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
5
页
3.Dimensions of the tester
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
6
页
二.
Sensor
1.Dimensions and installation diagram
Installation diagram
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
7
页
2.Wire rope tension sensor dimensions
三、Method and description of wire rope tension tester
1、Install the wire rope tension sensor and connect the sensor USB ports to IN1-IN8 input ports of the tester in
sequence. The actual number of sensors selected can be selected according to the number of wire rope, and the
sensor can be installed on the wire rope under the car rope head (can measure the car weight and the load in the
car) or on the wire rope under the heavy rope head (can measure the weight of the weight).
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
8
页
1、Press the ON/OFF switch power button of the tester. After the tester is turned on, turn on the red indicator in
the middle of each sensor.
2、Enter the Farmer APP on the tablet as shown in Figure 1, add test items and fill in the project leader.
3、As shown in Figure 1, the tablet enters the Farmer APP software, adds the test items and fills in the project leader
4、 Select the corresponding button according to the number of elevator wire ropes (1-8 wire ropes correspond to
CH1-CH8, for example :6 wire ropes can be clicked to select CH1-CH6 button), and select the corresponding wire
rope rope diameter button according to the rope diameter. Select the corresponding button according to the actual
traction ratio. Enter the Settings menu for Bluetooth binding.
Select wire rope quantity
Select wire rope diameter
Picture 1
Project Information:
Name: xxx test
Person in charge: xxx
Select according to the actual
traction ratio
setup menu
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
9
页
5、After entering the setting menu, enter password "fms" as shown in Figure 2 for binding devices, click "Scan
device" as shown in Figure 4 to scan the wire rope tension tester, select the device named "HC-08" to connect to
the wire rope tension tester through Bluetooth.
口令 fms
Picture 3
Picture 2
Picture 4
Picture 5
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
10
页
6 、 As shown in Figure 6, the screen of the wire rope tension tester changes from "network connection" to
"network connection successful", marking the completion of the Bluetooth connection between the tablet
computer and the wire rope tension tester.
Picture 6
Picture 7
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
11
页
7、 Click "Equipment debugging" to enter the stress column diagram of each steel wire rope as shown in Figure 8.
The stress of the steel wire rope can be adjusted by adjusting the tightness of the tie rod nut of the steel wire rope
head. When all the columns are even, each wire rope is stressed evenly.
Picture 8
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
12
页
8、Click "Run test" to enter the stress line diagram of each steel wire rope as shown in Figure 9, and you can
intuitively see the stress situation of each steel wire rope during the operation of the elevator.
Picture 9
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
13
页
四.
Application scope Working principle and main features
1.Wire rope tension tester application range
Wire rope tension tester has been widely used in many fields. First, it is often used in construction
projects to test the tension of lifting equipment, lifting machinery or other similar devices. Secondly, it is
also necessary to use the tester for the detection of ship mooring lines, various guides and buoys on offshore
platforms in ocean engineering. In addition, there is also a greater demand in the mining industry, bridge
construction and giant mechanical transport.
2."Wire rope tension tester" working principle
Wire rope tension tester is a special equipment for measuring wire rope tension. When the wire rope is
stretched, there is a strain, that is, a change in the shape and size of the object. This strain can be detected by
a tension sensor mounted on the wire rope and connected to a digital display or computer. When the wire
rope is stressed, the tension sensor will measure and convert into the corresponding electrical signal, and the
data will be transmitted to the display screen or computer through the cable for processing and output, so as
to achieve the working function of the wire rope stress test.
3.main feature
（1）
The device can accurately measure the tension of the wire rope and provide reliable data as a
reference.
（2）
It can effectively help to check and evaluate the health of the wire rope, timely detection and
avoidance of potential failures and safety hazards.
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
－
14
页
（3） In addition, this test instrument is simple, convenient and flexible to operate, and is suitable for a
variety of different specifications and types of wire rope.
五.
Technical Specifications
1
Applied range
Suitable for tensile test of wire rope on traction elevators, lifting equipment or
other similar devices
2
weighting error
≤1.5％(-20～55℃)
3
Output form
Wire rope stress column diagram and line diagram
4
Communication mode
100m point-to-point visual transmission distance (with gain antenna)
5
Transmission distance
100m
6
Operating temperature
-20~55℃
7
Power supply
AC 220V rechargeable, built-in battery
8
Function extension
Connect the Bluetooth tablet for viewing
9
Dimension parameter
Diameter of wire rope：8-16mm
Sensor size：180*150*50mm³
Wire rope tension tester size ：94*128*55mm³
Tablet size：205*125*10mm³
：If the strength exceeds the limit parameters listed above, it may cause the wire rope tension tester t
o work abnormally or cause permanent damage.
Technical File of SRSTS-WL-UX Wire rope tension test system
第
15
—
15
页
promise
⒈The wire rope tension tester in the factory within one year product quality problems, free replacement
(product seal damage will not be accepted).
⒉If you have special functional requirements, please write to us.
⒊If the wire rope tension tester is abnormal during use, please contact us directly.
Other
1. Attachments:
user's manual
1piece
sensor
8set
Wire rope tension tester
1set
Wire rope tension tester charger
1set
tablet PC
1set
Tablet charger
1set
⒉Address book：：
Xi’AN EXCELLENT ELECTROMECHANICAL CO.,LTD
TEL
(029)88416613 85565714 （029）85568478
fax
029-85565714-886
Address
7D，Block A, Olympic Building, 14th Chang An North Road, Xi'an, Shaanxi,China
postcode
710061
Technical Support：0086-18092639752 0086-18092639750
